Vertical Garden / Living Wall Calculator

Size a living wall or green facade: choose a system, check the saturated structural load, get planting density, automated irrigation sizing, an itemised bill of materials, an indicative budget and a multi-year cost of ownership.

All calculators
Inputs

Horizontal span of the wall to be greened.

Vertical height of the planted area.

Drives planting density, weight, water demand and cost.

Indoor walls need supplementary grow-lighting and recirculating irrigation.

Drives plant choice and outdoor water demand.

8 advanced inputs hidden. Switch to Advanced to fine-tune.

Confidencelow· 45Complexitylow· 10

Order what you need for this job

Ad · Some links are sponsored. We may earn a small commission at no extra cost to you. Suppliers are chosen for fit, not commission.

Wall area (m²)
10
Plants needed
300
Saturated load (kg/m²)
75m²
Total saturated load (kg)
750kg
Water demand (L/day)
15
Indicative total (£)
5,568
Indicative cost (£/m²)
557m²
Living wall specification — Modular hydroponic panels

10 m² exterior wall (4 × 2.5 m). All figures are indicative UK trade benchmarks — confirm against a structural survey and supplier quotes.

Plants

300

30 plants/m²

Saturated load

75

kg/m²

Water

15

L/day

Indicative

£557

per m²

Saturated load ≈ 75 kg/m² (750 kg total). Commission a structural survey of the host wall and fixing design before proceeding.

Automated irrigation is essential for this system — hand-watering leads to plant failure and voids most supplier warranties.

Frost risk — winterise the irrigation (drain down / trace heating, Oct–Nov) and specify frost-hardy species only.

Structure

  • Saturated dead load75 kg/m²
  • Total saturated load750 kg
  • Growing medium150 L (3 × 50 L bags)
  • Modules / cassettes40

Irrigation

  • Daily water demand15 L/day
  • Peak (summer)24 L/day
  • Annual consumption≈ 3,750 L/yr
  • Reservoir tank100 L
  • Pump dutySmall submersible (~500 L/hr)
  • Drip line≈ 39 m

Bill of materials

  • Waterproof membrane (EPDM) · 10 m²£120
  • Ventilation battens (25–50 mm gap) · 10 m²£60
  • Cement particle backing board (12 mm, A2) · 10 m²£220
  • HDPE root barrier · 10 m²£40
  • Galvanised subframe rails (600 mm centres) · 10 m²£350
  • Planting modules / cassettes · 40 modules£1,680
  • Growing medium (50 L) · 3 bags£27
  • Plug plants (P9–P12) · 300 plants£1,200
  • Concealed drainage gutter · 4 m£112
  • Powder-coated edge trim · 13 m£117
  • Irrigation header + drip line · 39 m£47
  • Pump & digital controller · 1 set£320
  • Reservoir tank · 100 L£140
  • Fittings, valves & fertigation dosing · 1 set£180
  • Sealed chemical anchor fixings · 10 m²£80

Indicative budget

  • Materials£4,693
  • Labour (~25 hrs @ £35/hr)£875
  • Estimated install total£5,568

Indicative UK supply + labour; excludes access equipment, delivery and VAT. Refine against real quotes.

Cost of ownership

  • Maintenance visits4/year
  • Annual maintenance£450/yr
  • Plant replacement≈ 7% of plants/yr
  • Expected lifespan15+ years
  • Maintenance over 10 yrs£5,340

Why a living wall

A dense evergreen wall improves the host wall's U-value by up to ~25%, buffers heat and noise (~5–10 dB), filters PM2.5–PM10 and NO₂, intercepts rainfall to ease surface-water runoff (SuDS), and counts towards Biodiversity Net Gain and BREEAM ecology credits when maintained under contract.
